Rotary Union Slip Ring

Rotary union slip nplhaib yog ib qho khoom siv hluav taws xob tshwj xeeb sib txuas siv los xa cov hluav taws xob hluav taws xob, tam sim no, lossis cov ntaub ntawv ntawm kev sib hloov lossis viav vias qhov chaw thiab qhov chaw ruaj khov.

Main feature

1. Kev sib txuas hluav taws xob ruaj khov: Lub nplhaib sib koom ua ke siv cov txhuam hniav los yog txhuam hniav kom tiv tauj lub nplhaib conductive, uas muaj cov hluav taws xob zoo sib txuas ruaj khov thiab tuaj yeem tswj cov teeb liab ruaj khov thaum sib hloov.

2. Kev sib kis ceev ceev: lub nplhaib sib koom ua ke tuaj yeem txhawb nqa cov ntaub ntawv xa mus ceev, uas yog tsim rau lub sijhawm uas muaj cov ntaub ntawv loj lossis cov teeb liab ntau zaus yuav tsum tau xa mus.

3. Zoo hnav tsis kam: cov nplhaib conductive thiab txhuam los yog txhuam feem ntau yog ua los ntawm cov ntaub ntawv hnav-tiv taus, uas muaj kev hnav zoo thiab tuaj yeem ua haujlwm ntev.

4. Kev ntseeg siab: lub nplhaib sib koom ua ke tau raug tsim thiab tsim, muaj kev ntseeg siab, thiab tuaj yeem ua haujlwm ib txwm nyob rau hauv ib puag ncig hnyav.

Rotary Joint Slip Rings yog dav siv nyob rau hauv ntau lub sijhawm uas yuav tsum muaj kev sib txuas hluav taws xob, xws li: cov khoom siv hluav taws xob, aerospace, hluav taws xob tsim hluav taws xob, kev saib xyuas kev ruaj ntseg, khoom siv kho mob thiab lwm yam kev lag luam tau dav siv.

Cov txheej txheem tsim khoom ntawm Rotary union slip nplhaib muaj ntau yam kev tsim khoom:

Ua ntej, kev npaj khoom siv

Kev xaiv cov khoom siv: Raws li kev siv lub nplhaib sib koom ua ke thiab kev ua haujlwm, xaiv cov khoom tsim nyog, xws li stainless hlau, tooj liab alloy, aluminium alloy lossis tshwj xeeb alloy. Cov ntaub ntawv no yuav tsum muaj cov khoom siv hluav taws xob zoo, hnav tsis kam, tiv thaiv corrosion thiab txaus txhua yam muaj zog.

Kev npaj coil: Rau qee hom kev sib tw rings, coil npaj (xws li cov ntawv dov hlau) yuav tsum tau ua rau cov kauj ruam tom ntej thiab ua cov kauj ruam.

Ob, stamping thiab sib sau

Stamping: Cov khoom npaj tau muab tso rau hauv lub tshuab xuas nrig ntaus thiab kwv yees cov duab ntawm lub nplhaib ntiv nplhaib yog stamped los ntawm kev tuag. Cov kauj ruam no yuav tsum muaj kev tswj xyuas meej ntawm qhov punching qhov tob thiab quab yuam kom paub meej qhov loj thiab cov duab ntawm lub nplhaib plam.

Kev Tsim: Tom qab raug nias, cov khoom yuav tsum tau tsim ntxiv kom tau txais qhov kawg ntiv nplhaib ntiv nplhaib. Cov txheej txheem tsim muaj xws li khoov, ncab, compression, thiab lwm yam, nyob ntawm seb tus qauv tsim ntawm lub nplhaib plam.

Thib peb, kev kho cua sov

Cua sov: lub nplhaib tsim lub nplhaib yog rhuab mus rau qhov tsim nyog kub los txhim kho nws cov yas thiab txo deformation kuj. Cov txheej txheem cua sov yuav muaj xws li hluav taws xob cua sov, induction cua sov, tiv tauj tshav kub hloov los yog nyob deb infrared cua sov.

quenching: Tom qab cua sov rau ib qho kub, lub nplhaib ntiv nplhaib yog txias sai heev los txhim kho nws cov tawv tawv thiab hnav tsis kam. Cov txheej txheem quenching yuav tsum muaj kev tswj xyuas nruj ntawm qhov txias txias thiab qhov nruab nrab txias kom tsis txhob tawg lossis deformation.

Tempering: Tom qab quenching, lub nplhaib plam yuav tsum tau tempered kom tshem tawm cov kev ntxhov siab sab hauv thiab txhim kho toughness. Qhov ntsuas kub thiab lub sijhawm yuav tsum tau txiav txim siab raws li cov khoom siv thiab kev ua haujlwm ntawm lub nplhaib ntiv nplhaib.

Plaub, kev kho deg

Ntxuav: Lub nplhaib plam yog ntxuav kom tshem tawm cov roj, oxides thiab lwm yam impurities ntawm qhov chaw. Cov txheej txheem ntxuav yuav suav nrog cov kauj ruam xws li ntxuav cov kuab tshuaj, ntxuav alkali, pickling, thiab lwm yam.

Txheej: Yuav kom txhim kho cov hluav taws xob conductivity, corrosion kuj thiab hnav tsis kam ntawm lub nplhaib ntiv nplhaib, nws yuav tsum tau coated nrog ib txheej ntawm hlau (xws li kub, nyiaj, tooj liab, thiab lwm yam) los yog hlau alloy. Cov txheej txheem plating yuav tsum muaj kev tswj hwm nruj ntawm da dej muaj pes tsawg leeg, tam sim no ceev thiab plating lub sij hawm.

Polishing: Lub nplhaib plam yog polished los txhim kho nws qhov chaw tiav thiab txo cov coefficient ntawm kev sib txhuam. Cov txheej txheem polishing yuav suav nrog cov kauj ruam xws li tshuab polishing, tshuaj polishing lossis electrochemical polishing.

Tsib. Kev sib dhos thiab kev sim

Kev sib dhos: Lub nplhaib plam yog sib sau ua ke nrog lwm yam khoom siv (xws li lub cev sib txuas, cov ntsaws ruaj ruaj, thiab lwm yam) los ua kom tiav kev sib koom ua ke. Cov txheej txheem sib dhos yuav tsum tau ua kom qhov tseeb ntawm qhov haum ntawm cov khoom thiab kev sib khi ua haujlwm.

Kev Ntsuas: Ntsuas qhov sib dhos ua ke, suav nrog kev ntsuas hluav taws xob (xws li kev tiv thaiv kev tiv thaiv, rwb thaiv tsev tiv thaiv, thiab lwm yam), kev ntsuas kev ua haujlwm zoo (xws li kev sib hloov lub neej, torque, thiab lwm yam) thiab kev ntsuas ib puag ncig (xws li ntsuas kub, av noo. cycle, thiab lwm yam). Cov txheej txheem xeem yuav tsum muaj kev tswj xyuas nruj ntawm cov kev sim thiab cov txheej txheem xeem kom paub tseeb tias qhov tseeb thiab kev ntseeg siab ntawm cov txiaj ntsig kev xeem.

Rau .Zoo tswj thiab tshuaj xyuas

Nyob rau hauv tag nrho cov txheej txheem ntau lawm, kev tswj kom zoo thiab tshuaj xyuas ntawm txhua tus txheej txheem yuav tsum tau ua. Qhov no suav nrog kev tshuaj xyuas cov khoom siv raw, stamping thiab tsim kev tshuaj xyuas zoo, kev tshuaj xyuas kev kho cua sov zoo, kev tshuaj xyuas qhov zoo thiab kev sib dhos thiab kev soj ntsuam zoo. Los ntawm kev tswj hwm nruj thiab tshuaj xyuas, peb tuaj yeem ua kom ntseeg tau tias qhov zoo ntawm lub nplhaib sib koom ua ke ua tau raws li cov qauv tsim thiab siv cov qauv.
